SKU: MOTU16A2
You might also need
Product Description
The MOTU 16A is a premium audio interface designed for professional musicians, producers, and audio engineers seeking uncompromising audio performance and versatile connectivity. Featuring renowned ESS Sabre32 DAC technology, the 16A delivers a dynamic range of 125 dB and impressively low harmonic distortion, offering pristine analogue sound clarity. Whether you're in the studio or on stage, the 16A provides 66 simultaneous audio channels with 16 analogue TRS inputs and outputs, ADAT optical ports, and a dedicated headphone output. Compatible with Thunderbolt 4 and USB4, it ensures ultra low latency and seamless integration across Mac, PC and iOS platforms. The integrated 64 channel mixer supports 32 bit floating point processing, and extensive routing capabilities make the 16A a powerful solution for mixing, patching, and audio networking. AVB Ethernet ports offer the ability to expand across multiple devices with low latency and perfect sync. Whether used as a hub in a professional setup or a standalone unit, the MOTU 16A stands as a future ready audio interface built on decades of engineering excellence.
Key Features:
- Superb Analogue Audio Performance:
ESS Sabre32 DAC technology delivers a dynamic range of 125 dB and crystal clear sound with ultra low harmonic distortion. - Universal Thunderbolt and USB Connectivity:
Supports Thunderbolt 4, USB4, USB3 and USB2 with plug and play compatibility across Mac, PC and iOS platforms. - Extensive I/O and Mixing Capabilities:
66 audio channels, 64 channel mixer with 32 bit floating point precision and 4 band parametric EQ on every channel.
Studio Grade Audio Conversion:
At the heart of the 16A is the ESS Sabre32 digital to analogue converter, a technology renowned for its exceptional clarity and dynamic range. Delivering up to 125 dB of dynamic range with virtually no distortion, it ensures that every audio detail is preserved. The analogue I/O supports both balanced and unbalanced signals, with digital gain and trim adjustments for precise level control. Whether recording, mixing or mastering, the 16A guarantees professional sound quality.
Flexible Connectivity and Routing:
The MOTU 16A features cutting edge connectivity with dual Thunderbolt 4 and USB4 ports for compatibility across a wide range of systems. With 16 TRS inputs and outputs, dual ADAT ports, and a dedicated headphone out, it covers all studio needs. Its virtual patchbay allows any input to be routed to any output or software destination, even across networked devices. This routing flexibility ensures efficient workflow in even the most complex setups.
Next Generation Audio Networking:
With integrated AVB networking, the 16A enables audio stream sharing between devices and hosts over Ethernet with ultra low latency and sample accurate clocking. It supports up to 128 channels in and out over the network and allows for daisy chaining or switch based topologies. Whether linking multiple interfaces or running audio across rooms, AVB ensures reliability and simplicity without requiring IT expertise. It is the perfect solution for scalable audio installations.
Specifications:
- Sample rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
- Analogue inputs: 16 x 1/4 inch TRS (balanced/unbalanced), max level: +21 dBu, +20 dB digital gain
- Analogue outputs: 16 x 1/4 inch TRS (balanced, DC coupled), max level: +21 dBu, -99 dB digital trim
- Digital I/O: 2 x ADAT optical ports (up to 16 channels), S/MUX support, stereo TOSLink/SPDIF via Bank A
- Headphone: 1 x 1/4 inch TRS stereo, output impedance: <1Ω, max output: 13.3 dBu
- Computer I/O: 2 x Thunderbolt 4 / USB4 Type C (40 Gbps), class compliant USB audio
- Included cable: 2 metre USB-C (40 Gbps, 240W), compatible with USB2 Type A via adapter
- Round Trip Latency: ~1.8 ms at 96 kHz with 32-sample buffer
- Total Audio I/O: 66 channels (32 in / 34 out at 1x), 50 channels at 2x, 34 channels at 4x
- Networking: 2 x AVB Gigabit Ethernet ports, 128 channels I/O at up to 96 kHz
- Sync I/O: BNC Word Clock in and out/thru, all sample rates supported
- Displays: Dual 3.9 inch TFT screens, RGB 24-bit colour
- Power: Internal 100–240V auto switching supply, 50–60 Hz
- Dimensions: 48.26 x 31.1 x 4.44 cm (19 x 12.25 x 1.75 inches)
- Weight: 5 kg (11 lbs)
- macOS Requirements: macOS 12 or later, Intel or Apple silicon, 4 GB RAM (8 GB recommended)
- Windows Requirements: Windows 10 22H2 or later, 11 23H2 or later, Intel/AMD x64
- iOS Requirements: iOS 17.5 or later, M-series chip required for Thunderbolt driver support
- Included Software: CueMix Pro, MOTU Performer Lite, 6 GB of loops and samples
