Lab Gruppen FA2402 2x 240W Commercial Amplifier
With Direct Drive Technology and Energy Star Certification
FREE UK Delivery
Earn 519 Loyalty Points
Want to Click and Collect or try items at our Guildford Store?
The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.
The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.
Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.
If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.
Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.
If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.
Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.
SKU: 000-DA504-00010
You might also need
Product Description
Here's what Lab Gruppen say about the Lab Gruppen FA2402 2x 240W Commercial Amplifier:
2 x 240 Watt dual-channel Amplifier provides the perfect solution for commercial and industrial applications requiring great sounding distributed audio coupled with power conservation and reduced operating expense. Capable of delivering high-quality sound over both Low-Z (4/8 Ohm) and High-Z (70/100 V) loudspeaker configurations offering extreme flexibility on every channel. FA2402 is easy to install and operate – even for non-technical personnel. Simply put, the FA2402 is ideal-suited for bars & restaurants, retail destinations, hotels, corporate, education or other venues needing background music and/or a public address system.
Energy Star * Certified
Not only does FA602’s direct drive constant power technology provide superior audio performance and reliability, it also consumes less mains power than competing models, which has earned it Energy Star * certification.
This amazing technology makes it possible to design and build powerful amplifier systems that not only save money on the electrical bill, but also reduce the requirements and cost at the installation for the mains supply. In fact, it is likely that installation can be done utilizing the in-place mains infrastructure. This adds up to significant installation and operational savings and protects the environment.
Easy to Install
The FA602 comes equipped with rubber feet, enabling the amps to be placed on a desk, shelf or any clear surface without any additional installation requirements. However, optional rack mounting hardware is also supplied, allowing one or several models to be housed and protected inside an enclosure. This adds extensive flexibility as a single product can be housed in a half 19" rack or full rack enclosure as well as a pair of amplifiers can easily be mounted side-by-side in a single rack space. With the included brackets the unit can also be mounted to a wall or under a table/shelf.
Specifications
Maximum Output Power
4 or 8 Ω per channel
240 W
Number of Ouput Channels
Number
2
Minimun Load Impedance
4 Ω mode
4 Ω
8 Ω mode
8 Ω
70 V output mod
20 Ω
100 V output mode
41 Ω
Controls
Front
N/A
Rear
Gain control, input sensitivty select (4 dBu / -10 dBV), load config (4 Ω / 8 Ω / 70 V / 100 V), switchable 80 Hz high-pass filter
Indicators
Power
On (blue), standby (yellow)
Limit (red LED), per channel
Input clip, output limit
Signal (green LED), per channel
>1.23 mV (-56 dBu)
Fault (red LED)
Overheat, DC fault, over current etc
System
Inputs
2 x 3-pin 5.08 mm Euroblock connector
Input impedance
10 kΩ unbalanced, 20 kΩ balance
Input sensitivty
Balanced: 1.23 V (+4 dBu) or 316 mV (-10 dBV)
Maximum input level
9.75 V (+22 dBu)
Outputs
1 x 4-pin 5.08 mm Euroblock connector
Output circuit type
Class D
Remote connector
2 x RJ45 Ethernet connecto
Performance
Distortion, 1/8 rated power
<0.5%
Frequency response
20 Hz to 20 kHz, +0.5 / -1 dB
Crosstalk
>65 dB
Signal-to-nois
>100 dBA
High-pass filter
80 Hz HPF
Circuit Protection
Cooling
Convection-cooled, fanless
Amplifier protection
Thermal protection, over current protection, DC protection, high frequency protection
Load protection
Controlled start and shutdown behaviour, DC-fault protection
Power Supply, Voltage
Main voltage
100-240 V~, 50/60 Hz with active power factor correction
Power consumption 1/8th rated power @ 4 Ω
120 W
Mains connector
Standard IEC connector
Dimensions / Weight
Dimensions (H x W x D)
44 x 218 x 280 mm (1.7 x 8.6 x 11.0")
Weight
2.6 kg (5.7 lbs)
Finish
Brushed black anodized aluminum chassis with black painted steel bottom
Approvals
CE, WEEE, CCC, cTUVus, PSE, RCM, RoHS, FCC part 15 Class B, Energy Star 3.0
