EVH 5150III LBX-S 15W Head
FREE UK Delivery
Earn 599 Loyalty Points
Want to Click and Collect or try items at our Guildford Store?
The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.
The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.
Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.
If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.
Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.
If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.
Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.
SKU: 2256026000
You might also need
Product Description
EVH have hit it out the park once again; the 5150III 15W LBX-S Head manages to pack a seriously punchy, classic tone into a compact 15-watt amp design.
Tonal Blend
Don't be fooled by this amps small dimensions - it still manages to punch well above its weight. It combines a Red 'full burn' channel, with a green 'clean' channel. This makes for a nice contrast between the two. You get cleans of astounding clarity which are juxtaposed by a high-gain, modern British sound.
Using the footswitch, harness the powerful, fiery overdriven tones (that's perfect for lead playing) of the Red channel; or, if you prefer, turn up the gain for a more blues-influenced sound on the Green channel.
Excellent Engineering
This lunchbox head is equipped with two JJ EL84 power tubes and four JJ ECC83S (12AX7) preamp tubes. Alongside this, there's shared EQ resonance/presence controls and dual-concentric gain and volume controls. These ensure you have precise, separate control over each individual channel.
Ready for the Home, Studio, or Stage
Wherever you like to play, this head is ready for the challenge. A 1/4 power switch can be used to lower the head to 3.5 watts - which is especially useful if you don't want to disturb your neighbours. It can also be used when playing live (or in the studio) for a tighter, spongier sound. A one-button footswitch, effects loop and dual parallel speaker output jacks only increase the units versatility further.
Visual Embellishments
A black front panel combined with a metal grill cage makes for one seriously sleek looking piece of gear. It's then stamped with the immediately recognisable EVH logo. Not a fan of the streamlined colour palette though? No worries - EVH have solved that too. A built-in LED backlighting system bathes the cage in red or green (matching whichever channel you currently have selected).
Features
- Includes a 5-foot speaker cable.
- 1-button footswitch (with 1/4" input jack).
- Effects loop.
- Dual parallel speaker output jacks.
- Four JJ ECC83S preamp tubes.
- Two JJ EL84 power tubes.
- Fully adjustable bias control ports.
- Impedance selection (4, 8, 16 ohms).
- LED backlight (green or red depending on your selected channel).
- Dual gain, high, mid, low, dual volume, presence and resonance.
- Two channels.
- Crafted from a durable aluminium/steel housing.
- 15-watt head.
Specifications
- Amplifier Type: Tube
- Inputs: One - 1/4”
- Channels: Two: (Green) Clean/(Red) Full Burn
- Controls: Dual Gain, Low, Mid, High, Dual Volume, Presence,
- Resonance
- Effects Loop: 1/4” (Send/Return)
- Speaker Jack: Two - 1/4” Parallel
- Wattage: 15 Watts
- Preamp Tubes: 4 x JJ ECC83S (12AX7)
- Power Tubes: 2 x JJ EL84
- Rectifier: Solid State
- Cabinet Material: Aluminium/Steel Chassis
- Grill: Black Metal
- Amplifier Covering: Black
- Front Panel: Black
- Handle: Vinyl with Metal Insert and Black End Caps
- Knobs: Black Chicken-Head Style Pointer
- Power Cable: IEC
- Footswitch: 1-Button Footswitch Included
- Recommended Cover: Optional P/N 0221600006
- Other Features: LED Backlight (Green/Red) - On/Off Selectable
- Included Accessories: 5-Foot Speaker Cable
- Dimensions: 7” (17.8 cm) H x 12.5” (31.2 cm) W x 6” (15.3 cm) D
- Weight: 15 lbs (6.80 kg)
